| Hardware Specifications |
|---|
| Copper Ports | 5 10/100/1000BASE-T RJ45 Ethernet ports including
3 LAN ports (Ports 1 to 3)
1 LAN/WAN port (Port 4)
1 WAN port (Port 5) | | Serial Interface | RJ45 serial port | | LoRa Antenna | 2 dBi external antennas with SMA connectors for LoRa | | DI & DO Interfaces | 2 Digital Input (DI):
Level 0: -24V~2.1V (±0.1V)
Level 1: 2.1V~24V (±0.1V)
Input Load to 24V DC, 10mA max.
2 Digital Output (DO):
Open collector to 24V DC, 100mA max. | | Connector | Removable 6-pin terminal block for power input
Pin 1/2 for Power 1, Pin 3/4 for fault alarm, Pin 5/6 for Power 2 | | Reset Button | < 5 sec: System reboot
> 5 sec: Factory default | | Enclosure | IP30 metal case | | Installation | DIN-rail, desktop, wall-mounting | | LED Indicators | System:
P1 (Green)
P2 (Green)
Alarm (Red)
I/O (Red)
LoRa (Green)
Ethernet Interfaces (Ports 1-4 and WAN Port):
1000 LNK/ACT (Green)
10/100 LNK/ACT (Amber)
Wi-Fi:
2.4G(Green)
5G(Green) | | Dimensions (W x D x H) | 50 x 135 x 135 mm | | Weight | 0.9 kg | | Power Requirements – DC | 9~54V DC, 1.3A Max. | | Power Consumption | 12.5 watts/ 42.7 BTU | | LoRaWAN |
|---|
| Frequency Band | LCG-300W-EU:863~870MHz (IN865/EU868/RU864)
LCG-300W-US: 902~928MHz (US915/AU915/KR920/AS923) | | Receiving Sensitivity | -142.5dBm | | Output Power | 27dBm Max. | | Wireless |
|---|
| Standard | IEEE 802.11a/n/ac/ax 5GHz
IEEE 802.11g/b/n/ax 2.4GHz | | Band Mode | 2.4G & 5G concurrent mode | | Frequency Range | 2.4GHz
America FCC: 2.412~2.462GHz
Europe ETSI: 2.412GHz~2.472GHz
5GHz
5.15GHz ~5.875GHz | | Operating Channels | 2.4GHz
America FCC: 1~11
Europe ETSI: 1~13
5GHz
America FCC:
Non-DFS: 36, 40, 44, 48, 149,153,157,161,165
DFS: 52, 56, 60, 64, 100, 104, 108, 112, 116, 132, 136, 140
Europe ETSI:
Non-DFS: 36, 40, 44, 48
DFS: 52, 56, 60, 64, 100, 104, 108, 112, 116, 120, 124, 128, 132, 136, 140
*5GHz channel list may vary in different countries according to their regulations. | | Channel Width | 20MHz, 40MHz, 80MHz | | Data Transmission Rates | Transmit: 600 Mbps* for 2.4 GHz and 1200 Mbps* for 5 GHz
Receive: 600 Mbps* for 2.4 GHz and 1200 Mbps* for 5 GHz
*The estimated transmission distance is based on the theory. The actual distance may vary in different environments. | | Transmission Power | 11g/n
HT20: 20dBm +/- 1.5dbm @MCS7
HT40: 17dBm@MCS7
11a/n
HT20: 19.5dBm+/- 1.5dbm @MCS7
HT40: 17dBm@MCS7
11ac
HT20: 20+/-1.5dBm @MCS8
HT40: 4.5+/-1.5dBm @MCS9
HT80: 4.5+/-1.5dBm @MCS9
11ax
HT20: 20+/-1.5dBm @MCS9
HT40: 17 +/- 1.5dBm @MCS9
HT80: 14.5 +/- 1.5dBm @MCS11 | | Encryption Security | WEP (64/128-bit)
WPA / WPA2 (TKIP/AES)
WPA-PSK / WPA2-PSK (TKIP/AES) / WPA3-PSK (TKIP/AES)
802.1x Authenticator | | Wireless Advanced | Wi-Fi Multimedia (WMM)
Auto channel selection
Wireless output power management
MAC address filtering | | Max. SSID | 8 (4 per radio) | | Max. Wireless Client | 128 (64 per radio)
(100 is suggested, depending on usage) |
| Advanced Functions VPN IPSec/Remote Server (Net-to-Net, Host-to-Net) GRE PPTP Server L2TP Server SSL Server/Client (Open VPN) VPN Tunnels Max. 60 VPN Throughput Max. 60Mbps Encryption Methods DES, 3DES, AES or AES-128/192/256 encrypting Authentication Methods MD5/SHA-1/SHA-256/SHA-384/SHA-512 authentication algorithm Management Basic Management Interfaces Web browser SNMP v1, v2c PLANET Smart Discovery utility/UNI-NMS supported Secure Management Interfaces SSHv2, TLSv1.2, SNMP v3 System Log System Event Log Others Setup wizard Dashboard System status/service Statistics Connection status Auto reboot Diagnostics Standards Conformance Regulatory Compliance CE, FCC Environment Operating Temperature: -40 ~ 75 degrees C Relative humidity: 5 ~ 90% (non-condensing) Storage Temperature: -40 ~ 85 degrees C Relative humidity: 5 ~ 90% (non-condensing)
|
