LREC9712HT

https://www.landextech.com/web/image/product.template/116/image_1920?unique=5b7bf96
(0 review)

PCIe x4 Dual-port Gigabit Ethernet Network Adapter
Key Features
-Based on Intel I350
-Equipped with two 1G RJ45 ports, supporting 10/100/1000Mbps data transfer rate.
-Fault-tolerance and redundancy by bundling and aggregating multiple ports simultaneously to extend network bandwidth and safeguard network performance.

0.00 AED 0.0 AED 0.00 AED 5% Tax Excluded ​​

0.00 AED 5% Tax Excluded ​​

Call Now !

This combination does not exist.

Contact Us
LR-LINK

Terms and Conditions
- Standard Manufacture Warranty.
- Rate exclusive of (5%) UAE VAT.
- Delivery lead time: 1 - 2 days business days.
- Free UAE Shipping (Terms & Conditions apply).

Share

LREC9712HT is a PCIe x4 dual-port Gigabit ethernet network adapter developed by Linkreal CO.,LTD. based on Intel I350 chip program, compatible with PCIe x8 and x16 channels. The adapter is designed for servers and server clusters and other network applications. It can realize fault tolerance and redundancy by bundling multiple ports into a group to expand network bandwidth and guarantee network performance, and it can automatically detect and realize real-time routing of communications from the faulty ports to other members of the same group for uninterrupted high-performance communications.

The LREC9712HT features integrated hardware acceleration to perform TCP/UDP/IP checksum offloading and TCP segmentation tasks. The host processing technology can offload the gas pedal. The host processing technology can offload the gas pedal, freeing up the CPU resource footprint to free up more CPU resources for other applications.

The LREC9712HT adopts a compact interface structure to better utilize server space, and allows two network ports to work simultaneously in full-duplex operation mode for high-performance network communication in a Gigabit Ethernet connection.

PCIe2.1 x4 Dual-port Gigabit Ethernet Network Adapter (Net-swift WX1860A2 Based): LRES2024PT


Product Reference Site Link


Controller

Intel I350

Cable medium

Copper

Fiber Type

1000Base-T Cat 5E & Cat6 or higher: up to 100m

100Base-Tx Cat5, Cat 5E & Cat6 or higher: up to 100m

10Base-T Category 3, 4, 5, 5E & Cat6 or higher: up to 100m

Bracket Height

Low Profile & Full Height

Max Power(w)

4.0 W

Connector

2 * 8-Pin RJ45

Bus Type

PCIe v2.1 (2.5GT/s & 5.0GT/s) x4; x8, x16 compatible

Data rate per port

10/100/1000Mbps

Power Supply

PCIe

Protocol Support

IEEE 802.3ab 1000BASE-T Gigabit Ethernet

IEEE 802.3u 100BASE-TX Fast Ethernet

IEEE 802.3z

IEEE 1588

IEEE 802.3ad

IEEE 802.3az - Energy Efficient Ethernet

PXE

No

DPDK

Yes

WoL

Yes

iSCSI

No

Jumbo Frames

Yes

FCoE

No

System Support

* Windows XP /7 /8 /8.1 /10

* Windows Server 2003 / R2

* Windows Server 2008 / R2

* Windows Server 2012 / R2

* Windows Server 2016 / R2

* Windows Server 2019 / R2

* RHEL/CentOS 6.x / 7.x or later

* Ubuntu 14.x / 16.x or later

* FreeBSD 9 / 10 / 11 or later

* Linux Stable Kernel version 2.6.x/3.x / 4.xor later

* Vmware ESX/ESXi 4.x / 5.xor later









LED Indicators

1000Mbps

ACT

Green Blink

LINK

Orange Link

100Mbps

ACT

Green Blink

LINK

Green Link

10Mbps

ACT

Green Blink

LINK

/



Environment Features

Operating Temperature

0℃ to 55℃ (32 ℉ to 131 ℉)

Storage Temperature

-40 ℃ to 70 ℃ (-40℉ to 158 ℉)

Storage Humidity

Maximum: 90% non-condensing relative humidity at 35 ℃

Certification

FCC，CE，RoHS

Catalogue page EN
